Type D Telemetry Expansion

$14.99

An add-on for the Type D system of displays. This installs in your XBOX and transmits Fan speed, CPU, temps and Ambient temps to all of your Type D displays. Detailed setup and install instructions are located on GitHub.

Installation

Solder SDA from the LCP header to Pin 7, SCL from the LPC to pin 6, GND to GNV, and 5v from the LPV to 5v on the S3

Mount to the RF shield with VHB tape or foam tape

Download the PC Viewer app:

Type-D PC Viewer

Most recent firmware is required for this to work along with the XBMC4Gamers script for app titles to work as expected. Script installation instructions can be found on the GitHub along with the script download.

An add-on for the Type D system of displays. This installs in your XBOX and transmits Fan speed, CPU, temps and Ambient temps to all of your Type D displays. Detailed setup and install instructions are located on GitHub.

Installation

Solder SDA from the LCP header to Pin 7, SCL from the LPC to pin 6, GND to GNV, and 5v from the LPV to 5v on the S3

Mount to the RF shield with VHB tape or foam tape

Download the PC Viewer app:

Type-D PC Viewer

Most recent firmware is required for this to work along with the XBMC4Gamers script for app titles to work as expected. Script installation instructions can be found on the GitHub along with the script download.
